Product Specifications
Maximum Servo Torque | 1173oz-in (84.47 kg-cm) @ 6.0V, 1209 oz-in (87.06 kg-cm) @ 7.4V, 1453.5 oz-in (104.66 kg-cm) @ 8.4V |
Application | 1/5 scale off-road |
Product Weight | 6.3 oz (178.6g) |
Spline Count | 15 - Tooth |
Deadband | Micro sec: <1 |
Product Height | 1.84 in (27.2mm) |
Product Length | 2.47 in (62.7mm) |
Connector Wire Length | 6 in (152mm) |
Product Width | 1.18 in (30mm) |
Type | Surface |
Bushing Or Bearing | Bearing |
Gear Type | Metal |
Servo Size Category | Large Scale |
Motor Type | Brushless |
Servo Operating Voltage | 6.0 - 8 |
